SD/HD/3G-SDI 1x2 Repeater & Distribution Amplifier with Re-clocking Function
SD/HD/3G-SDI 1x2 Distribution Amplifier & Extender



More pictures:
List Price: $198.00
Our Price: $148.50
You save $49.50!


Availability: Usually Ships in 24 Hours
Product Code: AAS-HD-SDE-122R

Overview Specifications What's in the Box / Warranty


This Economical device receives one SDI input and perfectly duplicates it. Then it re-transmits four SDI outputs for real time multi-viewing. It is a reliable video device splitting a SDI or HD-SDI video source to four HD-SDI or SD-SDI display at the same time.

This device is the same as the Economical type but It takes one input then re-clocks and equalizes the signal and distributes it to two identical outputs.
Features
  • SDI Standard: 3G-SDI, HD-SDI, SD-SDI
  • Data Rates: 270/1483/1485 Mbps
  • Signal Type: SMPTE 292M, SMPTE 259M
  • Two separately buffered outputs
  • Cable equalization (Beldon 1694A) and signal retiming
  • Re-clocking function capability – unlimited repeater connection
  • Dual color LED indication of input lock and rate
  • Pass all ancillary data
  • 5V~24V DC
