SD/HD/3G-SDI to HDMI Converter - Standard Series
SD/HD/3G-SDI to HDMI Converter - Standard Series



More pictures:
List Price: $120.00
Our Price: $90.00
You save $30.00!


Availability: Usually Ships in 24 Hours
Product Code: AAS-HD-SD-HDMI

Overview Specifications What's in the Box / Warranty


This device converts a single channel SDI signal to different kinds of HD Multimedia HDMI signal/VGA/S-Video/CVBS signal. It integrates SDI Cable equalizer and reclocker to enhance video performance and stability. Simultaneously, it also separates and converts the audio signals of SDI, embedding it to HDMI signal or output to analog audio DACs.
Features
  • Support SDI input format: 480i, 576i, 720p50/60, 1080p24/25/30, 1080i 50/60, 1080p50/60.
  • Support SMPTE 425M (A level and B level), SMPTE424M, SMPTE292M, SMPTE259M-C.
  • Carry 1 channel SDI signal loop out.
  • Max. cable length (Belden 1694A): SD-SDI 400m/1300ft, HD-SDI 200m/600ft, 3G-SDI 140m/450ft
  • Automatically embed SDI audio signal to HDMI signal.
  • User selectable output format (HDMI SDI BNC)
  • 5V~24V DC
